Independent Suction Feeder
●Stainless steel hopper, engine overload protective device
●XTL-300/450 integrated design, with small bulk and very light
●The whole series are equipped with cloth filter net and automatic clearing device
●The whole series are equipped with manual control switch, convenient for the machine to switch power when it's at height
Contact Us
Independent Suction Feeder
Technical Parameter

PARAMETERS
Machine type Fan type Motor power (kw) Conveying pipe diameter (mm) Conveying capacity (kg/hr) Hopper capacity (L) Voltage specification Extemal size L×W×H(mm) Net weight (kg)
XTL-300G Carbon brush type 1.1 38 300 7.5 1φ 220V 50HZ 340×300×815 12
XTL-330U 1.1 38 300 7.5 1φ 220V 50HZ 355×300×600 14
XTL-450U Inductive type 0.75 38 200 7.5 3φ 380V 50HZ 355×300×780 25
Ningbo Xin Bai Le Intelligent Machinery Manufacturing Co., Ltd.
