Air Cooled Chiller
●Cooling temperature range 5~35℃
●Equipped with stainless steel insulated water tank, with long service life and no pollution
●Refrigerated medium uses R22, with good refrigerating effect
●Refrigerating system adopts various precise control, can accurately control the system stablity
●Compressors and pumps are all with overload protection
●Shell condenser, with fast heat conduction and good heat dissipation effect
●Adopt original precision temperature control meter of famous brand, the display accuracy reaches ±0.5°C
Contact Us
Air Cooled Chiller
Technical Parameter

PARAMETERS
Machine type XC-05ACI XC-10ACI XC-15ACI XC-20ACI XC-30ACI XC-40ACI XC-50ACI
Refrigeration kw 15 29.5 44 58.5 86 116 140
10³KCAL/F 12.9 25.6 38 54.4 74.1 100 120
Souree(V/PH/HZ) 380/3/50
Input power(kw) 4.7 9.6 15 19.8 28.6 42.8 58.8
Compressor typ TTurbine type


Compressor power(kw) 3.75 7.5 11.9 15.5 22.5 30 37.5
Pump powe(kw) 0.55/1.1 1.1/1.5 1.5/2.2 2.2/3
5.5 5.5
Chilled water flow(m³h) 3.6/12.5 12.5-20 20/25 25/30 30/40 45 45
Evaporator type Coil tube Shell and tube type


Water tank volume(L) 70 83 150 200 285 300 300
Condenser Shell and tube type


Refrigerant R22
Throttling mode Expansion valve
Protector High and low voltage phase loss reverse overload
Extemal size(mm) HxWxH 1450×600×1180 1550×800×1420 1900×900×16802310×1080×17602600×1000×19002900×1100×2100
