Positive Displacement Mixer

●Simultaneous measurement, no need for blending, mixing while metering
●Separated raw materials due to gravity difference can be fully mixed
●Raw materials with different granule sizes and shapes can be fully mixed
●No blender mixing, thus avoiding static electricity generated from material blundering and making products to have colored patches
●Totally eliminate the trouble of powders brought by stirring
●Recipe can be stored, convenient for storage and calling recipe
●Can detect raw material block overloading, can automatically stop the machine for protection and giving an alarm

Positive Displacement Mixer

Technical Parameter

PARAMETERS

Machine type	XPM-40-2	XPM-40-3	XPM-40-4
Outside diameter of main/auxiliary screw(mm)	40x1/16×1	40×2/16x1	40×2/16×2
Main/auxiliary motor power(kw)	0.06×1/0.06×1	0.06×2/0.06x1	0.06×2/0.06×2
Primary/secondary reduction ratio	1:18×1/1:50×1	1:18×2/1:50x1	1:18×2/1:50×2
Maximum transmission capacity of single serew(kg/hr)	90/2	90/2	90/2
Maximum handling capacity	92	182	184
Storage hopper volume(L)	6	6	6
Low material level alarm	Optional	Optional	Optional
Overall dimension H x W x D( mm )	880x900×500	880x900×800	880×900×900
Net weight(kg)	66	78	90
