Powder Suction Machine
●The powder suction machine control device starts the engine to pick the air in the hopper, meanwhile closes the blanking device, thus creating negative pressure in the hopper
●Under negative pressure, the material in the storage tank are sucked into the hopper by delivery pipe
●When setting time, the motor stops working and the internal blanking device automatically opens the baffle, and the material flows out from the hopper and enters into the injection molding machine or other auxiliary machine
●With the advantages of convenient installation, simple operation, long distance, stable and reliable operation and high automation
Powder Suction Machine

PARAMETERS
Machine type Motor power (kw) Conveying capacity (kg/hr) Conveying height (m) Hopper capacity (L) Suction pipe diameter (mm) Extemal size L×W×D(mm) Net weight (kg)
XTL-1.5HP-F 1.1 42 4 7.5 38 550×450×1150 46
XTL-2HP-F 1.5 550 4 7.5 38 550×450×1150 46
XTL-3HP-F 2.2 720 6 12 51 600×450×1200 75
XTL-4HP-F 3 850 6 12 51 600×450×1200 78
XTL-5HP-F 3.8 1050 6 12 51 600×450×1200 85
XTL-7.5HP-F 5.5 1250 8 50 63 1105×850×1870 156
XTL-10HP-F 7.5 1650 8 50 63 1105×850×1870 185
