Euro Auto Vacuum Loader
●Two-stage cyclone dust remover and large dust bucket remover filtration technology, easy and fast maintenance
●The whole series are matched with European stainless steel hopper, ensures raw materials are not polluted
●Convenient and fast cleaning of filters
●Selectively assembled with vacuum valve to protect fans

Contact Us
Euro Auto Vacuum Loader
Technical Parameter

PARAMETERS
Machine type Motor power (kw) Conveying capacity (kg/hr) Conveying height (m) Hopper capacity (L) Suction pipe diameter (mm) Extemal size L×W×H(mm) Net weight (kg)
XTL-800G 1.1 42 4 7.5 38 550×450×1150 46
XTL-900G 1.5 550 4 7.5 38 550×450×1150 46
XTL-3HP 2.2 720 6 12 51 600×450×1200 75
XTL-4HP 3 850 6 12 51 600×450×1200 78
XTL-5HP 3.8 1050 6 12 51 600×450×1200 85
XTL-7.5HP 5.5 1250 8 50 63 1105×850×1870 156
XTL-10HP 7.5 1650 8 50 63 1105×850×1870 185
