Intermediate Speed Side Machine
●The best shear Angle, small resistance, not easy to jam, improve cutting efficiency
●Optimized design, can effectively absorb the vibration produced by crushing
●Slow grinding, grinding material particles uniform less dust
●Easy disassembly design, saving time and effort in maintenance
●The body size is small, the bottom is equipped with casters, easy to move
●High safety operation design, in line with European safety standards
Intermediate Speed Side Machine

PARAMETERS
Machine type XG-2000 XG-3000 XG-5000
Rotational speed(rpm) 160 160 160
Number of rotating tools 18 30 50
Number of stationary tools 2+2 2+2 4+2
Rotor diameter(mm) 180 180 180
Rotor working width(mm) 180 300 500
Mincing room inlet(mm) 270×180 270×300 270×500
Driving power(kw) 1.5 2.2 3.7
Weight(kg) 164 200 260
Overall dimension(mm) H×W×D 1060×470×1330 910×700×1350 1020×700×1350
