Heat Free Dehumidification Drying and Feeding Combination
●Unique downdraft duct design, which can evenly disperse hot air, keep plastic dry, stabilize temperature,and improve drying efficiency; Models above and above use openable sight doors with good sealing and convenient material cleaning
●Europeanization non heat dehumidification hopper dryer, equipped with non heat regeneration air dryer,can provide low dew point dry air without heating, and dry with raw materials
●The Europeanization non heat dehumidification hopper dryer is equipped with a hot air recovery device as standard, which has no dust discharge, protects the environment, and saves energy
Heat Free Dehumidification Drying and Feeding Combination
PARAMETERS
Machine type Barrel capacity(L) Dry heater power (kw) Dry blow power (kw) External size (mm) Inlet duct diameter ΦA(inch) Outlet duct diameter ΦA(inch) Weight (kg)
XDL-40U-HD 40 3 0.12 1700×1100×850 1.5" 1.5" 70
XDL-80U-HD 80 3.9 0.12 1700×1200×850 3" 2" 85
XDL-120U-HD 120 4.5 0.12 1700×1200×850 3" 2" 100
XDL-160U-HD 160 6 0.15 1800×1300×850 3" 2" 130
XDL-230U-HD 230 9 0.15 2100×1300×850 3" 2" 155
